Tεχνικό φυλλάδιο:

Design: Michel Tortel



Tightness level
Optical compartment   IP 66 (*)
Electronic compartment   IP 66 (*)
Impact resistance​ Glass IK 08 (**)
Aerodynamic resistance (CxS) Teceo S 0.170m²
Teceo 1 0.135m²
Teceo 2 0.199m²
Nominal voltage  EU 220-240V - 50-60Hz
US 120-277V - 50-60Hz
Electrical class   EU - I or II (*) - US - 1
(*) according to IEC - EN 60598 (**) according to IEC - EN 62262
Weight  Teceo S 5.1kg | 11.2lbs
Teceo 1 9.6kg | 21.16lbs
Teceo 2 17.5kg | 38.58lbs
Materials
Body + cover   Die-cast aluminium
Protector   Tempered glass
Colour   AKZO light grey 150 sanded
  Any other RAL or AKZO colour upon request
 THE TECEO RANGE OFFERS AN OPTMISED TOTAL COST FOR STREET AND ROAD LIGHTING THROUGH PHOTOMETRICAL PERFORMANCES AND ENERGY SAVINGS





MAXIMUM ENERGY SAVINGS
A minimal total cost of ownership was the driving force behind the development of the Teceo range. It is equipped with LEDs and various dimming and remote management options for a dramatic reduction in energy consumption.

THE NEW TECEO S VERSION
The new addition to the Teceo range, which has become the market benchmark recognised by independent bodies, is the Teceo S , that was designed for low-height applications such as residential streets, car parks and bike paths.

LENSOFLEX®2 AND LENSOFLEX®3
Teceo luminaires of Schreder have been equipped with the LensoFlex®2 and LensoFlex®3 photometric engines that have been specifically developed for lighting spaces where the well-being and safety of people using the environment are essential.

SMART LIGHTING
With a conventional solution, the depreciation of the luminous flux over time leads to excess lighting and thus too much energy consumption when the luminaires are installed. The efficiency slowly declines to reach the minimum required level at the end of the installation's service life (graph A).
The Teceo luminaires work differently by operating with a constant luminous flux (Constant Light Output - CLO).
They control precisely and autonomously their energy needs during the luminaires' life cycle to provide the required level constantly - no more and no less - throughtout the service life (graph B).
This can generate additional energy savings of up to 10% over the luminaire lifetime.



BACK LIGHT CONTROL - PREVENTING INTRUSIVE LIGHT
As an option, some versions of the Teceo can be equipped with a Back Light Control system.
Thanks to an additional control plate inside the luminaire body,
light spill from the back of the luminaire is minimised to avoid intrusive light on buildings.

Light distribution without Back Light Control



Light distribution with Back Light Control










 ΠΛΕΥΡΙΚΗ ΕΜΦΑΝΙΣΗ

TECEO S TECEO 1       TECEO 2
A                    450 mm | 17.7" 607mm | 23.9"

     788mm |  31"

B                       99mm | 3.9" 113mm | 4.4"

    119mm |  4.7"





ΜΠΡΟΣΤΙΝΗ ΕΜΦΑΝΙΣΗ

TECEO S TECEO 1         TECEO 2
C                     252mm | 9.9" 318mm | 12.5"

439mm | 4.7"

PHOTOMETRY

TECEO S

LENSOFLEX®2

Lifetime residual flux @ tq 25°C (**)

          @100.000h
Number of LEDs Neutral white (4000K) - CRI 72 8 LEDs 16 LEDs 24 LEDs
Current: 200mA Luminaire flux range(lm)* - 1200 - 1400 1800 - 2200 90%
Power consumption (W) - 11 15,4
Current: 350mA Luminaire flux range(lm)* 1000 - 1200 1900 - 2400 2900 - 3600
Power consumption (W) 9,9 18,3 26,2
Current: 590mA Luminaire flux range(lm)* - - 4700 - 5800
Power consumption (W) - - 45,5
Current: 600mA Luminaire flux range(lm)* - 3100 - 3800 -
Power consumption (W) - 31,1 -
Current: 700mA Luminaire flux range(lm)* 2100 - 2200 4100 - 4400 5400 - 6600
Power consumption (W) 19,4 36,4 53,5
Current: 860mA Luminaire flux range(lm)* - 4200 - 5200 -
Power consumption (W) - 43 -
Current: 950mA Luminaire flux range(lm)* 2300 - 2800 - -
Power consumption (W) 25,1 - -
Current: 1000mA Luminaire flux range(lm)* - - 7000 - 8600
Power consumption (W) - - 78

(*) The initial flux and power consumption of the luminaire are indicative values and valid for 25°C ambient temperature. The real flux output of the luminaire depends on environmental conditions (e.g. temperature and pollution) and may vary with specific configurations. Communicated values are subject to tolerances in technology.
(**) In accordance with IES LM-80 - TM-21.

 TECEO 1

LENSOFLEX®2 and LENSOFLEX®3

Lifetime residual flux @ tq 25°C (**)


Number of LEDs Neutral white (4000K) - CRI 72 8 LEDS 16 LEDS 24 LEDS 32 LEDS 40 LEDS 48 LEDS @100.000h
Current: 350mA Luminaire flux range (lm)* 1000 - 1200 1900 - 2400 2900 - 3600 3900 - 4800 4900 - 6000 5900 - 7200 90%
Power consumption (W) 9,9 18,3 26,2 34,8 43 51,2
Current: 500mA Luminaire flux range (lm)* 1400 - 1700 2700 - 3300 4100 - 4900 5400 - 6600 6800 - 8200 8100 - 9900
Power consumption (W) 13,7 25,9 37,6 49,5 61,5 73
Current: 700mA Luminaire flux range (lm)* 1800 - 2200 3600 - 4400 5400 - 6500 7200 - 8700 9000 - 10900 10600 - 13000
Power consumption (W) 19,4 36,4 53,5 70 87 104

(*) The initial flux and power consumption of the luminaire are indicative values and valid for 25°C ambient temperature. The real flux output of the luminaire depends on environmental conditions (e.g. temperature and pollution) and may vary with specific configurations. Communicated values are subject to tolerances in technology.
(**) In accordance with IES LM-80 - TM-21.

 TECEO 2

LENSOFLEX®2 and LENSOFLEX®3

Lifetime residual flux
@ tq 25°C (**)


Number of LEDs Neutral white (4000K) - CRI 72 56 LEDs 64 LEDs 72 LEDs 80 LEDs 88 LEDs 96 LEDs 104 LEDs 112 LEDs 120 LEDs 128 LEDs 136 LEDs 144 LEDs @100.000h
Current: 350mA Luminaire flux range(lm)* 7000 - 8300 8000 - 9500 9000 - 10700 10000 - 11900 11000 - 13100 12000 - 14300 13000 - 15500 14000 - 16700 15000 - 17900 16000 - 19100 17000 - 20300 18000 - 21500 90%
Power consumption (W) 59,5 67,5 76 84 93 103 111 119 127 135 143 152
Current: 500mA Luminaire flux range(lm)* 9500 - 11400 10900 - 13000 12200 - 14600 13600 - 16200 14900 - 17800 16300 - 19500 19600 - 21100 19000 - 22700 16000 - 19100 21700 - 25900 - 24400 - 29200
Power consumption (W) 86 97 109 121 133 148 160 171 185 195 - 219
Current: 700mA Luminaire flux range(lm)* 12600 - 15100 14300 - 17100 16100 - 19300 17600 - 21100 - 21300 - 25400 23000 - 27500 24800 -29600 26500 - 31600 28300 - 33800 - -
Power consumption (W) 121 138 154 175 - 208 225 241 258 275 - -
(*) The initial flux and power consumption of the luminaire are indicative values and valid for 25°C ambient temperature. The real flux output of the luminaire depends on environmental conditions (e.g. temperature and pollution) and may vary with specific configurations. Communicated values are subject to tolerances in technology.
​(**) In accordance with IES LM-80 - TM-21.



LIGHT DISTRIBUTIONS



LED optic 5068 - Asymmetrical

LED optic 5120 - Asymmetrical



LED optic 5144 - Asymmetrical

LED optic 5244 - Asymmetrical



LED optic 5245 - Asymmetrical

LED optic 5246 - Asymmetrical



LED optic 5247 - Asymmetrical

LED optic 5248 - Asymmetrical



LED optic 5249 - Asymmetrical

LED optic 5250 - Asymmetrical



- Futureproof: Διαχρονικότητα στο σχεδιασμό για προσαρμογή με την εξέλιξη της τεχνολογίας
- Thermix®: Ιδανικός σχεδιασμός για απαγωγή θερμότητας
- Πληθώρα φωτομετρικών κατανομών
- Dimming: Δυνατότητα ρύθμισης της φωτεινής ροής
- Προστασία από υπερτάσεις 10kV, 10kA
